XCM40

XCM40 cutting and mixing drilling rig can be used in the construction of anti-seepage walls and retaining walls in deep foundation projects such as subway stations, building foundation pits, basements of high-rise buildings, underground parking lots, underground commercial streets, reservoir dams, ports, mines, environmental protection projects, etc. Cutter soil mixing (CSM) is a non-borrow soil mixing wall-forming method. The double-wheel cutter cuts into the soil, and when the cutter wheel crushes the soil, the pump conveys high-pressure cement slurry and air to the cutter through the guide rod. Then the cement slurry and air are fully stirred with loose soils to form anti-seepage walls, retaining walls or improve the formation, which is a new technology for efficient construction.

Product ID: XCMG-MACHINE-XCM40-C672B954
Equipment Type: Piling Machinery
Machine System: Piling Machinery
Compatible Brands: XCMG
Main Equipment Series: XCM40
Reference Numbers: XCMG-MACHINE-XCM40-C672B954
Condition: XCMG catalogue item
Availability: RFQ

Ask on WhatsApp Request a Quote

FITMENT

Compatibility & Identification

Reference Numbers: XCMG-MACHINE-XCM40-C672B954

TECHNICAL DATA

Technical Specifications

Product code	XCMG-MACHINE-XCM40-C672B954	Product name	XCM40
Category	Piling Machinery

Item	Unit	Parameter
Trench width	mm	700-1000
Maximum trench depth	m	40
Maximum torque	kN·m	2×80/100
Rotary speed	r/min	0-25
Trench length	mm	2800
Maximum hoisting force	kN	1000
Engine	-	Cummins QSX15
Engine power	kW	447
Emission standard	-	Euro III
Operating weight	t	165
